CAB-USBC-HDMI-C300F
SKU: 13750104
ShippingDetails
Have you ever wanted to share the screen of your laptop through HDMI, but couldn't do it because you didn't have a USB-C adapter with you? With Lightware's latest 3-meter-long cable, this and similar situations will no longer be an obstacle, because a single cable can solve your problem, if you don't have HDMI output on your device, whether it be a tablet, a smartphone or a laptop. On the source, it has a USB-C plug, while on the transmitter side, it has an HDMI end, making work more straightforward and efficient. This solution supports resolutions up to true 4K@60Hz (4:4:4) for crystal-clear video, and no special driver is required to install, making it ready for easy and immediate use.
Specification Table
| Interface | Connectors | 1 × USB Type-C male, 1 × HDMI Type-A male |
| Technical parameters | Maximum data speed | 18 Gbps |
| Video format | Up to 4096×2160@60Hz at RGB 4:4:4 and 5120×2160@30Hz at RGB 4:4:4 | |
| Control signal | HDCP 2.3, EDID, DDC, DisplayID | |
| Audio support | Yes | |
| Displayport alternate mode | Yes | |
| Power | No external power required | |
| Operating temperature | 0 °C to +60 °C | |
| Flammability | TBD |
| Physical parameters | Length | 3 m |
| Cable diameter | 4.9 mm | |
| Jacket material | TPE | |
| Wire material | Copper | |
| Mold material | Aluminum | |
| Pin coating | Gold-plated | |
| Bending radius | 40 mm | |
| Pulling force | TBD | |
| Compliance | RoHS, REACH (EC 1907/2006) | |
| Color | Black |
| Note | It is a uni-directional cable and only converts from USB-C to HDMI |
Features
3m length for comfortable use
Provides connectivity between USB‑C-equipped
sources and HDMI-only displays and devices
Supports resolutions up to true 4K@60Hz (4:4:4)
for crystal-clear video
HDCP 1.4 and 2.3 support for
carefree encrypted video and audio transfer
No special driver installation is required
and the cable is ready for easy and immediate use
No additional power source is required
for quick installation with a single cable
Soft touch TPE jacket
Advanced EDID passthrough
for flawless source-display compatibility
Other Features
The gold-plated robust connectors ensure excellent signal quality
Cable plug fits all USB-C notebooks and tablets
