CAB-USBC-T200X
SKU: 13740045
Coming soon2m (6.56ft) Full-Featured USB-C cable for USB4 Gen 3x2, 4K60 Video and 240W/5A Charging, Microcoax technology
Interested in this product?
Details
Specification Table
| Interface | Connectors | 2 × USB Type-C male |
| Technical parameters | Maximum data speed | 40 Gbps (20 Gbps/lane) |
| Data type | USB4 Gen 3×2, USB 2.0, USB 1.1 | |
| eMarker chip | Yes | |
| Displayport alternate mode | Yes, HBR3, 2-4-lane | |
| Video format | Up to 4096×2160@75Hz at RGB 4:4:4 and 5120×2160@60Hz at RGB 4:4:4 | |
| Number of USB3 tier | 0 | |
| Number of USB2 tier | 0 | |
| Rated voltage | 48 V | |
| Rated current | 5 A | |
| Operating temperature | –10 °C to +60 °C | |
| Flammability | TBD |
| Physical parameters | Length | 2 m |
| Cable diameter | 5.3 mm | |
| Jacket material | TPE | |
| Wire material | Copper, 28 AWG | |
| Mold material | Metal | |
| Pin coating | Gold-plated | |
| Bending radius | 21.2 mm | |
| Pulling force | 4 kg | |
| Compliance | RoHS, REACH (EC 1907/2006) | |
| Color | Black |
This Type-C to Type-C premium USB cable offers 240W charging, data speeds up to 40Gbps (20Gbps/lane) and allows users to connect their laptop or other devices to Lightware’s USB-C compatible extenders and switchers. The cable’s length of 2m is ideal for most meeting rooms and presenter’s desk applications.The cable proved itself to work with great efficiency with our USB-C capable Taurus UCX/TPX/TPN family as well as with various source devices. Its reliability, build quality and technical parameters make this accessory our number-one choice for projects involving USB-C connectivity.
Features
2m length for comfortable use
240Watt / 5A charging and eMarker
Fast Charging for powerful Laptops, tablets and phones
USB4 Gen 3x2 40Gbps (20Gbps/lane)
4K Webcam, SSD storage
Supporting peripherals via USB 2.0 up to 480 Mbps
Mouse, Keyboard, Thumb Drive, Speakerphone and Webcam
4 Lane DisplayPort Alt mode
4K60FPS Video and Audio
Robust TPE jacket for durable use
Premium metal connector housing
