HDMI-TPN-RX107D-SR
SKU: 91710008
ShippingSDVoE compatible HDMI 2.0 scaling receiver with Dante audio
Details
The HDMI-TPN-RX107D-SR scaling receiver is based on the SDVoE technology and allows users to receive HDMI 2.0 compliant video, audio and control signals through 10G Ethernet networks. Depending on the HDCP settings and the resolution of the various sources, the receiver can support seamless and fast switching between those sources by rescaling the video either to the resolution described by the EDID of the connected display, or to a custom resolution.
Beyond the benefits of receiving, rescaling, and seamlessly switching high-resolution video, the HDMI-TPN-RX107AU2K-SR can also handle various connectivity standards, including a 1G user Ethernet channel over the 10G link, as well as command injection into RS-232.
The built-in scaler can cater for adjusting the video content to the format of the attached display. Moreover, the scaler is also able to handle glitches in the video arriving at the input of the corresponding transmitter by outputting an uninterrupted HDMI signal.
When connected with Lightware's TPX family of products using a direct Ethernet connection, the HDMI-TPN-RX107AU2K-SR endpoint falls back to TPX mode to maintain transmission compatibility.
Video wall functionality is supported using the native SDVoE API.*
*Disclaimer: Video wall feature can be configured via the SDVoE API or using Semtech AV Manager. Please request guidance and documentation from the Lightware technical person. The Video wall function is not currently available through the LW3 protocol or Lightware's LDC software, or other user interface.
Features
Allows for the transmission of HDMI 2.0
embedded audio, Ethernet, RS-232 to multiple receiver devices through a 10G Ethernet switch
Supports HDMI 4K signal formats
4K UHD @60Hz RGB 4:4:4, up to 18 Gbps
Can be remote powered through CATx cable
PoE PD
Dolby Vision Support
HDR and Low Latency
Plug&Play compatible
with Lightware TPN devices
2 channels of LPCM audio embedded
in the HDMI stream can be de-embedded to Dante/AES67 streams
Offers scaling
for format conversion and uninterrupted output
Video wall functionality
is supported using the native SDVoE API.*
Other Features
HDCP 2.3 compliant
Ethernet extension (1 Gbps)
Command injection through IR
Command injection through RS-232
Compatible with third-party SDVoE devices and controllers
Compatible Devices
1 product
Supplied Accessories
3 products
